Admin Area Features

• Automated lifecycle management — Create, Suspend, Unsuspend, and Terminate all call the Xtream UI admin API automatically (Terminate disables the line and sets its expiry to now, since the documented API exposes no delete endpoint)
• Renew Subscription admin button, plus fully automatic renewal on the panel whenever a renewal invoice is paid (via the InvoicePaid hook) — already-active services only, so first-time orders are left to standard provisioning. Renewals extend from the panel’s current expiry when it’s still in the future, or from now when the line has already expired.
• Sync Expiry Date admin button to pull the current expiry straight from the panel and update the WHMCS next due date
• Test Connection support from Setup → Products/Services → Servers, calling the panel’s action=server&sub=list endpoint to confirm access
• Unified product configuration dashboard replacing the standard module-settings fields, split into Provisioning Settings, Client Area Styling, and Client Area Features Visibility
• Subscription duration control — 1, 3, 6, or 12 months, or a custom number of days (handy for short trials), added to the line’s expiry on create and renew
• Bouquet assignment — comma-separated panel bouquet IDs applied to every line or STB created for the product
• Max Connections setting controlling the number of simultaneous streams allowed per line/device
• Flexible credential generation — alphanumeric or numeric auto-generated usernames/passwords with a configurable length (4–32 characters), or customer-selected credentials collected via order custom fields
• Multi-panel support — resolves the correct panel automatically from the product’s assigned WHMCS server group, so multiple Xtream UI panels can run side by side
• Admin Service tab showing the live panel status (enabled/disabled), expiry date, and active/max connection usage, pulled straight from the panel
• Duplicate protection — panel “EXISTS” errors (username or MAC already in use) are caught and surfaced with a clear, readable message instead of a raw API error
• Automatic product custom fields — MAG Address (with MAC-format validation), IPTV Username, and IPTV Password fields are created automatically on any product using the module, so customers can supply their own credentials or MAC address when required
• Full module logging — every panel API request and response is recorded to the WHMCS Module Log, with passwords and the panel API key always masked before logging
• License status banner in the admin header with a one-click re-check when the license key is missing or invalid

Client Area Features

• Self-service credentials panel — Line customers see their server URL, username, and password (with a show/hide toggle and one-click copy); MAG customers see their MAG address and portal URL instead
• M3U / M3U Plus playlist downloads, plus a one-click “Copy Playlist” action, for Line-type services
• XMLTV EPG URL copy button for Line-type services
• MAG Portal URL and Watch Stream (WebTV) launcher links, each individually shown or hidden per product
• Live expiry date and connection usage (active/max), pulled from the panel each time the page loads
• Per-product visibility toggles for server URL, username, password, expiry date, connections, M3U playlist, EPG link, and WebTV — so each product can show only what’s relevant to that service type
• Client area translated into 26 languages, automatically matching the client’s active WHMCS session/account language, with an English fallback
• Theme-aware, responsive layout — adapts to Light or Dark mode (including a configurable dark/white CSS-class toggle for templates with their own mode switcher) and is fully responsive across mobile, tablet, laptop, and desktop
• Native Lagom template support — automatically maps to Lagom’s own theme variables (including Lagom Dark Mode) instead of using the module’s custom color settings

Package & Configuration Options

• Service Type — Line (M3U) or MAG Device (STB), set per product
• Subscription Duration — 1, 3, 6, or 12 months, or a custom number of days
• Bouquet IDs — comma-separated list of panel bouquet IDs to assign
• Max Connections — simultaneous connection limit per line
• Username/Password Generation — Generated Alphanumeric, Generated Numeric, or Customer Selected (via custom field), with a configurable generated-credential length
• M3U / Player URL, MAG Portal URL, and Web Portal / WebTV URL fields shown to customers
• Client Area Styling — Theme Mode (Light/Dark), Primary and Secondary colors for both light and dark mode (with one-click reset to defaults), and an optional mapping to your own template’s dark/white mode CSS classes (dark-only, white-only, or separate classes for both)
• Client Area Features Visibility — independent show/hide toggles for server URL, username/MAG address, password, expiry date, connections, M3U playlist, EPG link, and WebTV
• All settings are configured from a single dashboard on the product’s Module Settings tab and save with the standard WHMCS “Save Changes” button

Supported Panel & Service Types

• Panel: Xtream UI (Xtream Codes-style) panels, connected via the panel’s admin API (api.php, action=user|stb), authorized either by admin IP whitelist or an optional API key on builds that support it
• Service types: Line (M3U) accounts and MAG/STB devices
• Subscription lengths: 1, 3, 6, and 12 months, or a custom day count for trials
